Quick Details
Place of Origin：Zhejiang, China
Brand Name：Tengen
Model Number：NT3
Usage：LOW VOLTAGE
Breaking Capacity：High, 120KA
Safety Standards：IEC
Product name：fuse base
Rated voltage：AC500/690,DC440V
Rated current：400A
Material：DMC
Function class：gG/gL,gTR
Plating：Tin/Ni Plating
Certificate：Tuv,CE,CB,IEC,ISO,RoHs
Standard：IEC60269.2, GB13539.2
Supply Ability
600000 Piece/Pieces per Month fuse base
Packaging & Delivery
Packed in strong standard export carton box.
Port：Shanghai Port, China
Low Voltage nt fuse holder with knife contact fuse link
|
Type
|
Rated Voltage
(V)
|
Rated Current
(A)
|
Dimension(mm)
|
|
A
|
B
|
C
|
D
|
E
|
F
|
G
|
H
|
|
NT1
|
AC500/690,DC440
|
250A
|
200
|
175
|
58
|
10
|
38
|
82
|
25
|
30
|
|
NT2
|
AC500/690,DC440
|
400A
|
225
|
200
|
64
|
10
|
40
|
100
|
25
|
30
|
|
NT3
|
AC500/690,DC440
|
630A
|
240
|
216
|
64
|
10
|
40.5
|
105
|
25
|
30
|
